Minifold Amv 2R3
We are immensely proud to manufacture and supply the utmost qualityMinifold AMV 2R3. Our product is developed with precision using high quality components & leading techniques following the set industry norms. The product offered by us is well tested against various parameters of quality to supply a quality-driven range. Clientele can avail this product in 316 Stainless steel, Monel, Duplex & other exotic materials.
Features:
- High performance
- Long service life
- Easy to operate
Other Details:
- 1x isolation and 1x vent valve for instrument drain/vent applications
- All valves have 2-piece non-rotating hardened (17-4PH) tips as standard for bubble tight
- shut off & long service life
- Metal to Metal body bonnet seal for high pressure and high temperature sealing
- 2 x 6.5 mm diameter mounting holes as standard
- Temperature range 100 ºC to 230 ºC (400 ºC with G option)
- Available in 316 Stainless steel, Monel, Duplex & other exotic materials
- Mounting holes as standard to allow fixing to pipe stand or enclosures
- Complete material traceability
- Also available with material compliance to NACE
Specifications:
- For BSPT connection use R instead of N. eg. AMV 2R 3 8R
- For temperature rating of 400 ºC, Grafoil packing add - G to Part no
- All dimensions are in millimeter and for reference only
- Valve open tolerance is ±2 mm and other ±0.5 mm
