SITRANS F M flowmeters measure the volume flow of electrically-conductive fluids. Water, chemicals, food and beverage, slurries, sludge, paper stock, and mining slurries with magnetic particles are measured using SITRANS F M. The product range is divided into three types of electromagnetic meter:
SITRANS F M DN 2 to DN 2000 (1/12“ to 78“).
• Full transmitter program MAG 5000/ MAG 6000/MAG 6000 I Ex compact or remote mounting.
• Variety of inputs and outputs and bus communication modules; PROFIBUS PA/DP, FOUNDATION Fieldbus, HART and Modbus® RTU.
• MAG 1100/1100 HT sensor for general process industries.
• MAG 1100 F sensor for food and beverage and pharmaceutical industries.
• MAG 3100/MAG 3100 HT sensor for general process industry.
• MAG 3100P designed for process industry and the harsh requirements in the chemical industry.
• MAG 5100 W sensor designed for water and wastewater applications.
The SITRANS F C coriolis mass flowmeters measure the direct mass flow rate of liquids and gases in almost any application. It is a multivariable device delivering reliable information on mass flow, volume flow, temperature, density and concentration (e. g. Brix or Baume). Flexibility and high performance with the MASS 6000 Coriolis transmitter The flexible MASS 6000 transmitters, designed for high performance, easy operation ensuring a low cost of ownership.
• Variety of transmitter enclosures.
• Multiple I/O as standard and communication modules PROFIBUS PA/DP, FOUNDATION Fieldbus, MODBUS RTU and HART.
• SENSORPROM facilitating true plug and play.
• Advanced diagnostics for easy service.
• Fast signal processing enabling high
speed batching.
SIFLOW FC070 is a true multi-parameter coriolis transmitter ready for quick installation and system integration. SIFLOW FC070
is the most compact, space-saving and versatile transmitter available.
• Direct integration into SIMATIC S7 automation system.
• Standardized user interface – SIMATIC Manager, PCS7 and SIMATIC PDM.
• Compatible with the complete range of SITRANS F C coriolis sensor.
• Stand-alone functionality or third party PLC integration.
• Ultra compact space saving design in SIMATIC 40 mm standard module.
Battery-powered electromagnetic water meter, MAG 8000 DN 25 to DN 1200 (1‘‘ to 48‘‘).
Designed for the water industry, the MAG 8000 program is a battery-powered solution that makes it easier than ever to install a reliable water meter virtually anywhere.
• Drinking water approvals.
• MI 001 EU Approval.
• OIML R49 type approval.
• Battery lifetime up to 6 years.
• Mains powered 24 V AC/DC, 115 V AC/ 230 V AC with battery backup.
• IP68 (NEMA 6P) enclosure for sensor and transmitter in compact or remote version.
High power electromagnetic alternating field flowmeter, TRANSMAG 2 DN 15 to DN 1000 (1/1‘‘ to 40‘‘).
Specially designed for heavy mining slurries with or without magnetic particles as well as the most difficult applications in the pulp and paper industry.
• A wide choice of corrosion-resistant liner materials.
• Heavy duty industrial enclosure.
• No movable parts.
SITRANS F US ultrasonic flowmeters are available as in-line and clamp-on versions. Both meter types can be used with homogeneous conductive and non-conductive liquids and gases (only clamp-on). In addition to standard volume flow, they can also provide information on media quality and temperature. Meter calibration can be certified to industry standards.
Ultrasonic in-line flowmeters are suitable for industrial applications with pipe sizes ranging from DN 50 to DN 1200 (2” to 48”).
Full 2 and 4-track sensors are available in combination with the SITRANS FUS060 transmitter.
• Option between mild and stainless steel sensors.
• Transducers can be exchanged without interrupting operation.
The SONOKIT system up to DN 4000 (160”) is designed for in-line retrofitting on all existing pipelines as a 1-track or 2-track flowmeter. The unique design enables installation on empty pipes or pipes under pressure without process shut-down.
• Robust version can be buried and withstands constant flooding.
• Outstanding accuracy; the bigger the pipe, the more accurate the result.
For the utility industry the 2-track flowmeters, SITRANS FUS380 and FUE380, are designed to measure water flow in district heating plants, local networks, boiler stations, substations and other general water applications.
• Custody transfer approvals for district heating custody transfer applications.
• Battery or mains power enables installation where needed. Battery lifetime is 6 years.
• Ideal for heatmetering together with the SITRANS FUE950 energy calculator.
Ultrasonic clamp-on flowmeters provide highly accurate liquid and gas flow measurement. The external transducers can quickly and easily be installed on the outside of the pipes ranging from DN 6 to DN 9140 (0.25” to 360”) in size.
Clamp-on ultrasonic flowmeters are available in six different families dedicated to each of their main industry:
• SITRANS FUS1010 for general applications
• SITRANS FUP1010 for portable meter
• SITRANS FUE1010 for energy
• SITRANS FUH1010 for hydrocarbon
• SITRANS FUG1010 for gas
• SITRANS FUS1020 for water and wastewater
The SITRANS FUE1010 and SITRANS FUP1010 are available as kits that come in a sturdy suitcase, containing all equipment necessary for performing flow measurement tasks. These kits are ideal for check metering of existing applications regardless of measurement technology or applications with no metering.
All clamp-on meters are characterized by easy installation with no need to cut pipe or stop the flow, minimal maintenance thanks to external transducers that do not require periodic cleaning, excellent accuracy and repeatability, no moving parts to wear or foul, and no pressure drop or energy loss.
SITRANS F X Vortex flowmeters provide accurate standard volumetric and mass flow measurement of steam, gases, conductive
and non-conductive liquids. The Vortex flowmeter functions as an “All-in-one-solution” with integrated temperature and pressure
compensation.
It is specially designed for applications that require reliable flow measuring independent of pressure, temperature, viscosity and density. This makes it perfectly applicable in especially the chemical industry, HVAC & power, food & beverage, oil & gas and pharma. The SITRANS F X Vortex flowmeter is available as flanged or sandwich version in the following configurations:
SITRANS FX300 single converter
is available as a volumetric and mass flowmeter:
• Volumetric flowmeter. Measurement of steam, gases and conductive and nonconductive liquids.
• Mass flowmeter. Measurement with temperature sensor for saturated steam compensation as standard feature. Option with a pressure and integrated temperature sensors for compensation of gases, wet gases, mixtures or steam.
• Option within pressure sensor is the isolation valve allowing the pressure sensor to be shut off for the purpose of pressure and leak testing of the pipeline or for being exchanged without interrupting the process.
SITRANS FX300 dual converter
is available as a volumetric and mass flowmeter:
• Dual measurement for twofold reliability.
• Redundant system with two independent sensors and two converters.
• Optimally suited for measurements in multi product pipelines.
• Each converter can be individually programmed for the given product.
• Measurement with temperature sensor for saturated steam compensation as standard feature.
SITRANS F R – rotary piston meters
Used to measure the volume flow of conductive and non-conductive liquids. High viscosity media, acids and alcoholbased concentrates are accurately recorded. Even measurements subject to calibration standards can be undertaken. No inflow and outflow runs required.
