Bottle Filling Machines

Features



• The filling machine will be operated automatic type with 2/4/6/8 heads preferably with diving nozzle type to avoid foaming during filling process.
• All the working parts of the machine coming in contact with the product are S.S.316 (filling cylinder & nozzle).
• Conveyor had inlet & outlet ends of the machine variable speed to synchronize with the filling the filling machine speed. The conveyor tailing width adjustable.
• Casing of the machine of S.S.304
• Filling accuracy for various volumes within range of +-0.5% on volume
• Filling head height will be adjustable.
• Main motor 1 HP (Siemens, Hindustan, Bharat Bijlee).
• Conveyor Motor ½ HP. (Siemens, Hindustan, Bharat Bijlee).



Bottle Washing Machines

• We are specialized in the processing and manufacturing of automatic rotary bottle washing machine. These machines are used to wash the containers of plastic, glass and so on and so forth. Moreover, these machines require low maintenance because of their durability. These machines are designed in such a way that they provide maximum benefit to our customers. Consequently, we have been reckoned as one of the most preeminent automatic rotary bottle washing machine manufacturers.
• Five wash (Four Inner and one outer).
• Stationary spray nozzles, Collection tray & recirculation system avoid contamination of water  cycle.
• To adjust sequence of washes as per customer's scope.
• Solenoid valve for each washing sequence reduce leakage & wastage of water.
• Higher pressure centrifugal pumps to clean bottle properly.
• Pumps and tanks are fitted on separate stand for easy cleaning & maintenance.
• Height adjustable bottle guide for pet or lightweight bottle.
• Separate control panel provide for locate as per customer's convenient and avoid any accident.



Automatic Auger Filler With Screw Conveyor

Features

1.	Sealing	Centre seal
2	Range	1 kg. , 2 kg. to 5kg.
3.	Out-put pouches per minute	5 to 15 pouch per min.
4.	Suitability	Any heat sealing films (laminates) or Alum foil based material
5.	Power Requirement	5 KW.( Motor, Main Motor, Heaters etc.)



Automatic Curd Cup Filling And Sealing Machine

• Cup filling machine is rotary cup filling machine for  curd in plastic cups.
• Cup filling machine is suitable for filling and lid sealing of cups.
• Suitable to fill 50ml, 100 ml, 250ml & 500ml.
• Rotary machine with 8-stational operation.
• Automatic single head filling unit, single head foil pick-up and sealing unit with automatic ejection  system.
• 2 HP motor driven
• SS.304/SS.316 contact parts power 415v-3, phase-50hz, heater 600w Compact model.
• No glass No filling system.



Single Head Hopper Piston Type Filling For Shrikhand

• Hopper size and Capacity 25Kg. to 30 Kg. Approx.
• Mechanical- ½ h.p. motor
• Operated by Pneumatically
• Filling Range.,200ml to 400ml
• Single phase..
• Speed 10 to 12 cups ( Depends on Operators)
• Cup pressing manual,



Tube Filling Machine

Features

Lami Tube Filling , Crimping & Batch Coding Machine



• Sturdy & compact design and simple in operation.
• Rotating disc with interchangeable sockets for different sizes.
• No Tube No Fill arrangement.
• S.S. Hopper of 25 kg capacity.
• 1st & 2nd station are for feeding of Tubes.
• 3rd station for vacuum cleaning (Optional).
• 4th station Empty.
• 5th station for No Tube No Fill Process with filling.
• 6th station – Pre Blowing Tubes.
• 7th station - Sealing Unit.
• 8th station – Batch Coding.
• Tailing controlled pneumatically.
