The company offers Fluid Bed Dryer that has accurate precision. Fluid Bed Dryer is used for the easy and even drying of chemical, pharmaceutical and food products. Our Fluid Bed Dryer comes with different documentations namely DQ, IQ, OQ, and FAT, as a part of standard procedure. This Fluid Bed Dryer facilitates easy operations.
Salient Features

• 65% open perforated air distribution plates along with Dutch weave mesh
• On line sampling Port
• 2.5kg. to 500kg. batch capacity
• Top Spry Granulation
• Explosion relief disc
• All contact parts are S.S. 316 as per GMP Standard
• Uniform Drying at low temperature
• Intrinsically safe earthing system ensures complete elimination of static charge
• Fan motor unit & Filtration unit can be placed in remote areas
• Heating mode electrical / steam / thermic fluid
• Top mounted pneumatic cylinder (directly coupled ) for shaking (without wire rope system)
• Minimum handling more Hygienic
• Pneumatically operated inflatable seals provided for filter bag and product container sealing with pressure switches & FRL to ensure fail safe operation

The company is the reputed Manufacturer, Exporter and Supplier of Fluid Bed Processor. The Fluid Bed Processor is used to convert wet powder into dry powder and in many other industrial processes. Our Fluid Bed Processor has a flame-proof construction. We offer Fluid Bed Processor at the market leading prices.
Salient Features

• GMP Compliant Model
• Flame proof construction
• Customised layout
• Contact parts in Stainless steel construction
• Pneumatic bag shaking arrangement
• Pneumatic cylinders to seal the bowl to the Retarding Chamber.
• Air Handling Unit with HEPA filter provided at air inlet for heating, dehumidification etc of Supply Air
• Scrubber provided at the air outlet to remove suspended particles from the air stream.
• Dehumidification of Air.
• PLC/HMI based operator panel.
• Bowl can be provided with vacuum conveying.
• Wash in Place system

Ribbon Blender comprises of a U-shaped horizontal trough along with a rotating double helical ribbon agitator. Ribbon Blenders have an agitator construction that facilitates a triple mixing action ensuring fast and efficient blending. We have designed Ribbon Blender in accurate dimensions and balanced configuration of the ribbons to manage easy movement of material within the container.

An alternate design to Ribbon Blender is the paddle agitator. In that, the paddles are positioned to move the material in opposing lateral directions. The paddle design is generally employed for friable materials and when batches as small as 15% of the total capacity are going to be mixed in the blender.
Used For Blending

• Pharmaceuticals
• Food products
• Chemicals
• Cosmetic products

We are a prime Octagonal Blender Manufacturer, Exporter and Supplier from Mumbai, Maharashtra. The Octagonal Blender, we offer, is widely used in the Pharmaceutical Industry for blending of dried granules and powders. Our Octagonal Blender blends material quickly and efficiently. We make available Octagonal Blender according to the client’s specifications, as needed.
Features

• Discharge out put via. Butter fly valve. (Pneumatic discharge can be provided)
• Safety guards provided with limit switch interlocked to motor which ensures safe operation
• Bump less rotation assured because of specially designed transmission chain sprocket
• All the contact parts made of SS 316 as per GMP standard
• Zero retention design
• To enhance the mixing, baffles are provided on central shaft
• Internal finish confirming 220 grits to 320 grits, outside mat finish180 grits
• Charging drum arrangement with Mechanical / hydraulic trolley
• Safe earthing system
• Optional Accessories/ Attachments
• Flame Proof Construction
• PLC with MMI
• VFD

The company offers Conta Blender, whose mixing efficiency is better than many other tumbling blenders like Double Cone, V or Octa. Our Conta Blender gives quick results by shuffling the products immediately giving a homogeneous blend within 5-20 min. The Conta Blender rotates in a diagonal direction and on an eccentric plane. The Conta Blender facilitates dust free transfer of powders.
Capacity available : 2 to 1000 Kgs.
Features

• Low-volume Active Blending
• Dust-free operations in solid dosage processing area
• Processing of different sizes of production batches in single equipment with scale up data.
• No Cleaning down time as the product container is mobile.
• No risk of De-blending on extended processing.
• Containerized transfer of processed material avoiding manual scooping.

We are the well-known Pharmaceutical Storage Tank/ Chemical Storage Tank Manufacturer, Exporter and Supplier in the market. We offer hygienic Pharmaceutical Storage Tank/ Chemical Storage Tank, which is used in various industries like pharmaceutical, food, agrochemical etc. We offer Pharmaceutical Storage Tank/ Chemical Storage Tank which has robust construction and is leak-proof. Our Pharmaceutical Storage Tank/ Chemical Storage Tank is available in different capacities, ranging from 50 litres to 20000 litres.

Availability : Capacity ranging from 50 to 200 litres

The company offers Inline Homogenizer that is leak- proof. The Inline Homogenizer provides versatile mixing. Our Inline Homogenizer is manufactured in is available from the capacity of 3 HP to 25 HP. We offer Inline Homogenizer at market leading prices.
Details

In Inline Homogenizer suction pipe (inlet pipe) is centrally mounted & outlet is radically mounted, therefore it is physically impossible for any material to pass from inlet to outlet without exposed to agitation.
The stator which surrounds rotor is available with various type of opening i.e. round, square, rectangular & with perforation also so that all the critical demand of Mixing, Emulsifying, Disintegration & Dispersion of solids, suspension can be met out by same equipment.
The machine is versatile & has completely revolutionized the traditional mixing techniques. Here close tolerance of rotor with the stator produces high hydraulic shearing & mechanical action that ensures that material entrapped between rotor & stator is subjected to tremendous shearing actions each minute

Capacities Available : 3 HP models to 25 HP models

The company offers Tray Dryer which is widely appreciated for its durability and strong construction. The company makes available Tray Dryers in different specifications, as demanded. The Tray Dryer is manufactured according to the GMP standards.
Finishing
The design and manufacture of the dryer is of high standard of GMP and has an aesthetic look. It is buffed externally to 150 grit matt finish and internally buffed to 220 grit mirror finish.

Vibro Sifter is circular unitary gyratory screens, which is used to separate mass composition of solids from solids. This Vibro Sifter is also used for gradation of materials as per particle size. We offer Vibro Sifter that is easy to dismantle and clean. We offer Vibro Sifter that has safe earthing system.
Details
The structuring of the machine has been designed in order to achieve the multiple plane vibration by suitable assembly of the specially designed Vibratory motor (constructed for this purpose) having eccentric weight at the top and bottom ends of the motor shaft. The motor is mounted vertically at the centre of the screening assembly, on a circular base by means of springs which allow the Unit to vibrate freely. The springs absorb the vibrations and prevent them to be transmitted on the floor.
The top weight causes vibration in the horizontal plane which causes the material to move across the screen towards the Periphery. The lower weight acts to tilt the machine which causes vibration in the vertical tangential axis. The angle of lead of the lower weight with relation to the upper weight provides variable control of the screening pattern.
Thus the material moves across the screen and also in the vertical and tangential planes enabling maximum screening.

The Liquid Manufacturing Plant is used in pharmaceutical industry for the production of Oral Liquids. The Liquid Syrup Manufacturing Plant offers facilities like minimum manual handling of Liquid. These Liquid Syrup Manufacturing Plants are available in different capacities ranging from 50 L to 20,000 L. We offer Liquid Syrup Manufacturing Plant at affordable prices.
Liquid Manufacturing Plant Consists

• Sugar Melting Vessel
• Pre-filtration unit
• Syrup Manufacturing Vessel
• Filtration unit
• Storage Vessel
• Control Panel
• Product Piping
• Working Platform

Multi Mill Machine is widely used for processes like wet and dry granulation, pulverization, etc. The Multi Mill Machine has application in various industries such as Pharmaceuticals, Chemicals, Ceramics, Cosmetics, Colors, Dyestuff, Food products etc. Multi Mill Machine is also used in the production of Pesticides, Fertilizers, Spices, Detergents, Insecticides, Plastic and Resins Industries. We offer Multi Mill Machine at market leading prices.
Details
Multi Mill unit consists of S.S. 304 quality hopper and processing chamber (can be provided is S.S. 316 quality at extra cost) with beaters assembly, motor, reversible switch, DOL starter, four speed step pulley, Suitable screen with painted pillar mounted on base plate, with castors.

Ointment Manufacturing Plant is widely used in the pharmaceutical & cosmetic industries for the production of Ointment, Cream, Lotions, Tooth Paste & other products. Our Ointment Manufacturing Plant has compliance with set industrial standards. We offer Ointment Manufacturing Plant at affordable prices.
Salient Features

• Suitable for dry mixing of products in powder form
• Easy for loading and unloading
• Easy for cleaning
• All contact parts are made out of SS304/SS316 or SS316 L quality material, as per customer requirement
• Simple design requires minimum maintenance
• Minimum man handling of Ointment
• Negligible vacuum drop during mixing & blending

Powder Transfer System, we offer, is more useful than most conventional systems. Powder Transfer System is widely used to dispense powders. Powder Transfer System is known to offer maximum benefit in the prevention of explosion or hazards of flammability. We offer Powder Transfer System that is manufactured using high quality components.
Features

• Used for products with difficult flow characteristics
• Reliable method to safely transfer and dispense powders
• Benefit in the prevention of explosion
• Benefit in the prevention of hazards of flammability

Jay Pharma Equipments offers Stainless Steel Reaction Vessel, which is used in the processing of many products like adhesives, chemicals, paper and pulp processing, etc. We offer Stainless Steel Reaction Vessel that has compliance with global industrial standards. Our Stainless Steel Reaction Vessel is acclaimed worldwide for its durability and optimal functionality.
Additional details
Modifications such as the addition of baffles to increase mixing shear have been made to these types of blenders. Each cylindrical leg has an access cover for easy material loading and cleaning.

Jay Pharma Equipments offers high performing Reactors, which are serving in adhesives processing, agriculture, chemical processing, cosmetics, food and beverages production, paints and coatings, paper and pulp processing. Modifications such as the addition of baffles to increase mixing shear have been made to these types of blenders. Each cylindrical leg has an access cover for easy material loading and cleaning.

Types Of Reaction Vessel

Jacketed, Limpet coil, Top open type, Top dish type etc

With an experience of nearly three decades, in providing solutions for the chemical process industry, JAY PHARMA EQUIPMENTS is ideally placed to offer you well engineered and optimum vacuum dryers to suit your application.

Our Rotocone Vacuum Dryers have C-GMP finish construction with an enclosed drive unit preinsulated and cladded with SS304 monoblock. They come with complete automation including safety interlock, batch records, vacuum and temperature control.

We also make other dryers like:
1. Rotary Vacuum Paddle Dryers
2. Spherical Paddle Chopper Dryers
3. Conical Screw Dryers.

In addition, we supply accessories like Cyclone Separator, High Vacuum Pump and Condenser, Heating and Cooling , System required for solvent recovery of complete system

Description / Specification of Valves

We are involved in offering a wide range of Valves to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Valves. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

Description / Specification of Lotion Mfg Plant

We are involved in offering a wide range of Lotion Mfg Plant to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Lotion Mfg Plant. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

Shampoos are typically viscous liquids, either clear or opaque (pearlised), containing 20–40% solids, adjusted to approximately pH 5.5. Most, but not all, have viscosities in the ratio of 500–1500 centipoise. A hair shampoo may be defined as a detergent specifically formulated for the washing of hair, and packaged in a user-convenient form. Typically, a shampoo must clean well, rinse easily, impart gloss to the hair, minimise tangle and not damage the hair structure, or the scalp or the eyes.

MANUFACTURING PROCESS

Shampoos are manufactured by simple slow blending in a stirred vessel. The vessel may be jacketed for heating. Vessels are normally closed type and subjected to vacuum to avoid excessive foaming when foaming agent is added. For best results contra type rotating stirrer is best used for shampoo manufacturing.
Ingredients are weighed or metered incrementally into the mixing vessel, with thorough mixing between each addition. A moderate amount of heat is used to reduce the viscosity and so facilitate ease of mixing.
Some pearlising agents are waxy solids at ambient temperature and require melting in a premixing vessels before use. Demineralised water is most commonly used in order to minimise contamination of the product.
No further processing is required after blending, & perfuming and the product may be packed off directly from the mixing vessel. Or may be transferred to storage vessels from where they are transferred to the filling machines.
Many companies make the bases for the shampoos where they do all the premxing of surfactants, sles, other ingredients and sell the same to major industries These industries are mainly called the formulators and in this second level processing will involve only the addition of water, colour and fragrance. In case of ayurvedic or herbal shampoos, they add their propriety formulae ingredients themselves so that no one knows the exact nature of ingredients and its details.

GENERAL

Hair Oil are typically viscous liquids, either clear or opaque. They come in various types from normal hair oils, ayurvedic, herbal, medicinal, etc and cater to different types of hairs.

MANUFACTURING PROCESS

Hair oils is one of the most simplest to manufacturer. Hair oil is manufactured in simple stirring type vessel at slow speed. The different type of oil bases are mixed as per the formulae and then active ingredients are added. Perfuming is done and then directly taken for filling.

VESSELS REQUIRED FOR A SHAMPOO PLANT

Oil Manufacturing Vessel
Manufacturing vessel is cylindrical vessels with dished bottom vessels. Top of the vessel loose lid Agitator assembly in the manufacturing vessel., slow speed Anchor agitator or paddle type agitator. Bottom outlet is provided. No additional gadgets are required for manufacturing hair oil

Storage Vessel
Storage vessel is simple vessel used to store Hair Oils. It is cylindrical type of vessel with dished bottom, loose top lid. Bottom valve is provided with din fittings to facilitate the pipeline connection. Its capacity is the same as the

Description / Specification of Talcum Powder Mfg Plant

We are involved in offering a wide range of Talcum Powder Mfg Plant to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Talcum Powder Mfg Plant. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

TOOTHPASTE MANUFACTURING MIXER consists of a Main Manufacturing Vessel also known as Contra Mixer. Contra Mixer as the name suggest works on the principle of Contra rotation of Blades for simultaneous beating and scraping operation. The mixer is highly versatile and mostly used for manufacturing Tooth Paste, Creams, Cosmetics and other viscous products.

The Mixing Assembly consists of series of paddle type blades of appropriate shape to move the material back towards the centre of the container. The paddle type blades are provided on the central shaft which runs through a hollow shaft on which other sets of blades are welded. Both the sets of blades intermeshes with each other and rotates in clockwise and anti-clockwise direction respectively and one sets also scraps the container wall for thorough and uniform mixing of the material.

The mixer is so designed to withstand high vacuum applied during the process for optimum mixing. Contra Mixer is provided with a jacket for cooling or heating as per the application. The vessel shall have a shell of suitable thickness with a hemispherical bottom and flanged top dish made out of S.S. 316 plate. The vessel shall be jacketed with MS jacket ( SS304 jacket provided on extra cost on demand, if required ) of suitable with stiffeners suitable for steam pressure of 4 to 5 Kg/cm2. The jacket shall be insulated with 50 mm thick glass wool insulation and shall be cladded with 16 SWG M.S. or SS304 material. The vessel shall be suitable for 600 to 700 mm of Hg vacuum and internal pressure of 3 Kgs / cm2.

The top lid of the Mixer m/c shall be provided with hydraulic lifting and lowering arrangement, if required. Hydraulic arrangement will consist of : ( Optional at extra cost )
a. Hard Crome plated HYDRAULIC CYLINDERS ( 2 Nos. )
b. Limit switches at upper and lower limits
c. Power pack with direction control valve by actuated

IMPORTANT SPECIAL FEATURES

• Capability to handle a large range of tube sizes
• Automatic cap tightening
• No-tube-no-fill device
• Automatic tube infeed
• Adjustable filling pump and several optional attachments
• Can handle tube diameters from 10 mm to 40 mm and lengths from 40 mm to 200 mm. ~ Automatic tube infeed with cassette loader.
• Simultaneous accessibility of many tube holders in case of manual infeed.
• Tube cleaning device for dust removal (particularly required for pharmaceutical and~ food products)
• Adjustable filling pump with different volumes:. - Ease in removal of pump components for cleaning and changeover. -Contact parts are corrosion resistant, - No-tube-no-fill device, - Blow off device to cut "Rat tail" of highly viscous products.- Photo-electric tube registration for automatic positioning of tube orientation. - Multiple folding stations for tube closure. - Code marking on the closure with digits and/or letters. -Transportation of filled tubes forward and backward.

The extractor can be applied to plant/herbal extraction in Chinese Traditional Medicine, foodstuff, chemical industry and so on. Equipped with an mixing system, it features higher efficiency,time-saving quality and high content of liquid drug in extraction.

The equipment can be used in Chinese Traditional Medicine, foodstuff and chemical industry. It can be applied to various processes as follows: drug-decocting under normal pressure or low pressure, digeratur, thermal refluxing, forced circulation, infiltration, extraction of aromatic oil, reclaim of organic solvent and etc. This device features higher efficiency, time-saving quality and high content of liquid drug in the course of extraction. The equipment employs the types of impeller blade and paddle blade as its agitation system. Using excellent materials, the device is widely applied to pharmacy, foodstuff and chemical industry.

Starch Paste Kettle Will Be Made Out Of S.S. 304 Rectangular Pipes Of 3 Mm Thk And Will Be An Independent Resting Type Frame Work Where No Foundation Will Be Required. The Kettle Will Be A Hemispherical Type Bowl With Either Steam / Oil / Water Heating Jacket Will Be Provded. The Kettle Will Be Manufactured From 2.5 Mm Thk S.S. 304 Sheet And The Jacket Will Be Of 2.5 Mm Mild Steel (In Case Of Steam Jacket The Thickness Will Be 4 Mm) . There Will Be Oil / Water Heated Fitted At The Back Bottom Side Of The Kettle. The Kettle Will Be Having A Worm Type Arrangement For Tilting . A Temperature Controller And A Temp Indicator Will Be Provided For Temp Control And Indication. The Kettle Will Be Insulated With 50 Mm Thk Glasswool Insulation And Claded With 16 Swg S.S. 304 Sheet. Kettle Will Be Buffed To 150 Grit Matt Finish Externally And Internally The Kettle Will Be Buffed To 220 Grit Mirror Finish

We offer a large variety of precision engineered a wide variety of exclusive Hand Filling Machine. Hand Filling Machine is manufacture by supreme quality of stainless steel and latest technology which is brought from the most trusted and most well known vendors. Hand Filling Machine widely used for the purpose of filling quickly and safes the time. Hand Filling Machine makes the filling easier and enjoyable. Depending upon the type of usage Hand Filling Machine can be availed in a range of sizes. Hand Filling Machine is available in reliable range of prices.

Features:

• Long life service
• Easily available
• Cost efficient
• High performance
