Description / Specification of Pouch Sealing Machine

We are involved in offering a wide range of Pouch Sealing Machine to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Pouch Sealing Machine. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

Fully automatic mechanically operated vertical pouch form, fill & seal machine to pack 'Viscous liquids' with exclusive design pneumatic piston filling system. Machine supported on heavy duty angular structure mounted on Castor wheel wrapped with stainless steel cabinet all contact parts are in stainless steel.
Technical Specifications:

• Feeding head: Pneumatic piston filling system.
• Production Speed: 30 - 35 sachets / min.
• Packing range: 50-150 ml/gm.
• Film Width: Up to 210 mm.
• Film Thickness: 60 to 80 microns.
• Film Material: Any heat sealable laminated film.
• Sealer heating system: Continues only.
• Filling Accuracy: +/- 3ml/gm.
• Inner Core Dia. of Film Roll: 70mm.
• Outer Dia. of the film Roll: Up to 350mm.
• Pouch Style: 3 or 4 side seal pillow pouch.
• Pouch Width: Up to 105 mm.
• Pouch Length: Up to 145 mm.
• Power Consumption: 1.2 kW / Hour.
• Peak Power: 3 kW.
• Air compressor: 2 Hp. 1 Phase, 230 V, AC 50 Hz.
• Air consumption: 4 CFM @ 20" C.
• Compressed air pressure: 6.5 kg/cm2
• Power requirement: Single Phase, 230 V, 50Hz.
• Pouch Counter: Provided.
• Date printing Device.: Optional.
• Machine Dimensions: 1500 (H) x 450 (W) x 450 (Depth).
• Net Weight: 350 to 450 kgs

Namkeen Pouch Packaging Machine at reasonable prices. Set up with timer belt controlled by stepper motor drive, the offered compilation has an alphanumeric, LCD back lit display through micro controller based system. Vastly demanded by food processing and packaging industries, the range is quite reasonable.
Features:

• Consistent performance
• Tough construction
• Low power consumption

Applications:

• Irregular shaped products such as potato chips, extruded food, banana chips, cheese balls, bakery
• Products Homogenous fine grained products such as tea powder, seeds, sugar, whole spices
• Homogenous coarse grained products such as rice, wheat, pulses, Sabudana
• Coarse products such as cashew nuts, almond, pistachio, whole spices
• Mix products such as namkeen, farsan,
• Industrial products such as lugs, screws, nails, bolts, nuts etc.
• Specially suited for Poha ( Rice Flakes), Murmure, corn flakes, candies, etc.
• Pharma products such as capsules, tablets, etc.

Specifications:

• Feeding head: 2/4/6 Weigh Filling System.
• Production Speed: 08 to 10 pouches per min.
• Packing range: 50gm to 500 gm.
• Film Width: Upto 410mm.
• Film Thickness: 60 – 80 Microns
• Film Material: Laminated Film.
• Sealer heating system: Continuous / Pneumatic Type
• Inner Core Dia. of Film Roll: 70mm.
• Outer Dia. of the Film Roll: Upto 350mm.
• Pouch Style: Three Side / Four side sealing.
• Pouch Width: 400 mm. Max
• Pouch Length: 150 mm.  Max
• Power Consumption: 1.5 KW / Hour.
• Machine Power: 3 KW.
• Power Requirement: 3 Phase, 415 V 50Hz.
• Machine Operation: PLC System
• Machine Dimensions: Basic Machine – 3.5 ft wide x 3.5 ft Length x 9.0 ft Height.
• Machine Gross weight: 350 to 450 Kg

Description / Specification of Pickle Pouch Packing Machine

We are involved in offering a wide range of Pickle Pouch Packing Machine to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Pickle Pouch Packing Machine. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

We are the leading manufacturer and supplier of Auger Filler Pouch Packing Machine or Automatic Collar Type Form Fill Seal Machine with Auger Fillers. It is an ideal pouch packaging machine with Servo operated Auger filler to pack various products at high speed like Flour, maize flour, custard powder, henna powder, Instant coffee powder, spices, milk powder, glucose powder, protein powder etc in center seal pillow type PP/ LDPE bags. our product are having such optional features like Controlled by PLC with color touch screen, AC Servo drive / AC Inverter drive for pulling paper, Self diagnostic, Easy loading of film roll.
Specifications:
• Filling Range: 50 gm to 1000 gm / 500 gm to 2000 gm Options:
• Servo driven Auger filler or clutch & brake driven auger filler
• Paper pulling option: Servo driven or through clutch & brake

We are dealing in Kurkure Pouch Packing Machine

Description / Specification of Turmeric Powder Pouch Packing Machine

We are involved in offering a wide range of Turmeric Powder Pouch Packing Machine to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Turmeric Powder Pouch Packing Machine. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

We are dealing in Spices Powder Pouch Packing Machine

Specifications:

• Feeding head: 2/4/6 Weigh Filling System.
• Production Speed: 08 to 10 pouches per min.
• Packing range: 50gm to 500 gm.
• Film Width: Upto 410mm.
• Film Thickness: 60 – 80 Microns
• Film Material: Laminated Film.
• Sealer heating system: Continuous / Pneumatic Type
• Inner Core Dia. of Film Roll: 70mm.
• Outer Dia. of the Film Roll: Upto 350mm.
• Pouch Style: Three Side / Four side sealing.
• Pouch Width: 400 mm. Max
• Pouch Length: 150 mm.  Max
• Power Consumption: 1.5 KW / Hour.
• Machine Power: 3 KW.
• Power Requirement: 3 Phase, 415 V 50Hz.
• Machine Operation: PLC System
• Machine Dimensions: Basic Machine – 3.5 ft wide x 3.5 ft Length x 9.0 ft Height.
• Machine Gross weight: 350 to 450 Kg

Description / Specification of Chilli Powder Pouch Packing Machine

We are involved in offering a wide range of Chilli Powder Pouch Packing Machine to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Chilli Powder Pouch Packing Machine. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

Tachnical Specifications:

• Feeding head: 2/4/6 Weigh Filling System.
• Production Speed: 08 to 10 pouches per min.
• Packing range: 05gm to 100 gm.
• Film Width: Upto 410mm.
• Film Thickness: 60 – 80 Microns
• Film Material: Laminated Film.
• Sealer heating system: Continuous / Pneumatic Type
• Inner Core Dia. of Film Roll: 70mm.
• Outer Dia. of the Film Roll: Upto 350mm.
• Pouch Style: Three Side / Four side sealing.
• Pouch Width: 400 mm. Max
• Pouch Length: 150 mm. Max
• Power Consumption: 1.5 KW / Hour.
• Machine Power: 3 KW.
• Power Requirement: 3 Phase, 415 V 50Hz.
• Machine Operation: PLC System
• Machine Dimensions: Basic Machine – 3.5 ft wide x 3.5 ft Length x 9.0 ft Height.
• Machine Gross weight: 350 to 450 Kg

Description / Specification of Semi Automatic Pickle Filling Machine

We are involved in offering a wide range of Semi Automatic Pickle Filling Machine to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Semi Automatic Pickle Filling Machine. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design
