Owing expertise we are offering various range of Pharmaceutical Scoop, to our clients. Keeping in mind requirement of our clients we are offering high quality of Pharmaceutical Scoop, The offered range of scoops is made using quality approved raw material and sophisticated machinery at our end. These scoops are available in various sizes and in different measuring portions.

We offer the finest quality Coating Pan that is used in the processing of Kurkure, Puff snacks, Namkeen, Dry Fruits, Chocolate, Fryums etc. It is available in different technical specifications as per the diverse needs of the clients and can be installed easily. Offered pan is manufactured by our professionals using superior-quality components and advanced technology at our hi-tech manufacturing unit. Our precious clients can also avail this Coating Pan in various customized options Features: Rust resistance Sturdiness Long working life High strength Application: Kurkure, Puff snacks, Namkeen, Dry Fruits, Chocolate, Fryums etc. Grace Food Processing & Packaging Machinery offers: Technical Specifications: A.C Motor: 2 H.P Gear box: 3" Capacity: 8-10 kg/batch

DESCRIPTION Stainless steel scrambler & un scrambler, which is familiar as turn table. This is built on SS square frame, solid guide rail & reduction gear box for jerk less & noiseless performance. Turntable is useful to ensure total synchronization, uniform flow of container and to take a turn at 90 degree to suit different machine and purpose in automatic liquid line. OPERATION Container inputs in turn table by manually or automatic will rotate on disk of turn table and exit through outlet, during rotation of container will guided by a SS strip, which will guide the container towards outlet path. SALIENT FEATURES ? Construction AISI S.S. 304 quality. ? Three step pulley for different speed. ? Special self-aligning bearings ensure smooth and trouble free operation. ? Suitable for different type of container. ? S.S. elegantly matt finished body. ? Reduction gears ensure jerk free and noiseless operation. ? Matt Finished body. OPTIONAL ? Castor Wheel with lock ? A/c Frequency Drive ? Acrylic Cover ? Tray for loading or unloading of container.

We offer a wide assortment of Octagonal Blender, which is the most suitable for blending the fragile free flow and most delicate materials like granules and powder in minimum possible time. The product is extensively used in industries like flour, drugs and pharmaceuticals, minerals, colour, metal powders, fibers and many other industries. Applications & Working Principle The machine is designed in all respects & fitted with 2 HP, TEFC, three phase, 415V, electric motor, standard reduction gear box & a starter. The body of the machine is in L shaped, fabricated structure & fitted with castor wheels for easy mobility. MOC for all contact part is AISI 304 or AISI 316 as per requirements.

Multi Mill is widely used for wet and dry granulation, pulverisation etc., in Pharmaceuticals, Chemicals, Cosmetics, Ceramics, Colours, Dyestuff, Food products etc. It also finds application in Pesticides, Fertilizers, Spices, Detergents, Insecticides, Plastics and Resins Industries. Salient Features : Direction of beaters can be changed by reversible switch from knife to impact forward and vice-versa All contact parts can be easily and quickly dismantled and cleaned Machine is designed for continuous operation Cylindrical screen for higher output Castors provided for mobility Flame proof Electricals can be provided at extra cost. Beaters and scrapper blades of SS 304 quality. Technical Specifications : Out Put : 50 kg to 200 kg/hour depending upon the product and the reduction required in size. Rotor assembly dia : 250 mm (approx.) Rotor speed : 750/ 1500/ 2300 /3000RPM. Beaters : 12 nos. with knife and impact edges.and 2 scraper blades Screen Dimension : Dia. (ID) 260 mm. Ht. 135 mm. Motor : TEFC, 3 HP/1440 RPM/ 440 V/50CS/ 3PH/ AC Starter : DOL with reversible switch. Material charging ht. : 1445 mm (approx.) Overall Dimensions : 870 x 965 x 1630 mm Ht. Net Weight : 275 kgs. (approx.) Gross weight : 425 kgs. (approx.) Case Dimensions : 1200x1550x1860 mm (HT) SS perforated Screen sizes (Holes dia in mm) (a) 0.5, 1.0, 1.5 (b) 2, 3, 4, 5, 6 (c) 7, 8, 10, 15, 20, 25SS Wire Mesh Sieve (a) 4, 6, 8, 10, 12, 14, 16, 20, 24, 30, 40, 50, 60 (b) 80, 100

We manufacture a wide range of Tray Dryer/ Drying Oven that is widely used for heating, ageing, drying and many more purpose. Our range of these ovens is designed for parallel placement of the material that results in increase in production and saves batch timing by convenient loading and unloading. This types of Tray Dryer is available with external temperature control panel, and high temperature can also be fabricated. Owing to the superior quality of our products, our range of these products is widely demanded in the market. Moreover, these ovens are available in various sizes and models to choose from. Application of Tray dryer Drying oven Tray Dryers are ideally suitable for drying chilies, spices, potato chips, onions, fish, garlic, grapes, cashew nuts, confectionery, macaroni, vermicelli, noodles, pizza, etc. It is also for used for drying pharmaceuticals, chemicals, powders, granules, plastic granules, powder coating etc. Heating is either by electric or steam or both combined. Various models are designed & manufacture to suit customer requirements. Custom-built models can be quoted on request.

We offer a wide range of very high quality Stainless Steel Rack at very affordable market price. These products are highly Eco-friendly and are manufactured at par with the international market level. These products are available in different standard size and can be custom-designed according to the needs of our customers. We believe in effective and timely delivery of the product once ordered by our clients, as customer's satisfaction is our major concern.

We are the specialist in IPC and Pharmaceutical Furniture in Stainless Steel. For your kind information and evaluation, so far, we have very successfully and efficiently handled / completed different kinds of Stainless Steel job works for our valued clients. We also enclosed complete information of our company. We are Manufacturing of all kind of S. S. Materials for :- Pharmaceuticals, Chemicals, Formulations, IPC, Bunker, Fabrication, S. S. Sheet Metal, Tanks, Vessels and Kitchen equipments, Extrusion plant Hopper/Barrel Guard, Pharmaceutical Machinery etc.

here are various products that we are known of and among all,Pharmaceutical Hospital Furniture deserve special mention.

This cabinet comprises of different racks which is used for storing purposes and also for placing products on top of the product. Using latest techniques and modern equipment, this product is going to last long without causing any problem.

Users can get this product from us at market leading prices.
