Welcome to 3 SEPARATION SYSTEMS
New Compact Ball Valve
DESCRIPTION:
- Material: PVC, CPVC, HT-CPVC
- Size: 1/2' - 4'; 20mm - 110mm ; DN15 - DN100
- Joint End: Socket, Threaded NPT, BSPF and PT
- Standard: ANSI, DIN, JIS, CNS
- Working Pressure: 150 PSI
- Operating Temperature: PVC(0~55℃); CPVC & HT-CPVC(0~95℃)
- Handle color : red, blue
- Valve body color : PVC(dark gray/white), CPVC(light gray), HT-CPVC (light yellow)
True Union Ball Valve
Description :
- Material: PVC, CPVC, PP, PVDF
- Size: 1/2' - 4'; 20mm - 110mm; DN15 - DN100
- Standard: ANSI, DIN, JIS
- Joint End: Flanges
- Working Pressure: 150 PSI
- Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
- Handle color : red, blue, green, orange
- Valve body color : PVC(dark gray), CPVC(light gray),
- PP(light yellow), PVDF(ivory)
Flanged True Union Ball Valve
DESCRIPTION:
- Material: PVC, CPVC, PP, PVDF
- Size: 1/2' - 4'; 20mm - 110mm; DN15 - DN100
- Standard: ANSI, DIN, JIS
- Joint End: Flanges
- Working Pressure: 150 PSI
- Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
- Handle color : red, blue, green, orange
- Valve body color : PVC(dark gray), CPVC(light gray),
- PP(light yellow), PVDF(ivory)
Electric Actuated Ball Valve
DESCRIPTION:
- Material: PVC, CPVC, PP, PVDF
- Size: 1/2' - 4'; 20mm - 110mm; DN15 - DN100
- Standard: ANSI, DIN, JIS
- Joint End: Socket, Threaded(NPT, PT, BSPF), Fusion, Welding
- Working Pressure: 150 PSI
- Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
- Valve body color : PVC(dark gray), CPVC(light gray),
- PP(light yellow), PVDF(ivory)
Pneumatic Actuated Ball Valve
DESCRIPTION:
- Material: PVC, CPVC, PP, PVDF
- Size: 1/2' - 4'; 20mm - 110mm; DN15 - DN100
- Standard: ANSI, DIN, JIS
- Joint End: Socket, Threaded(NPT, PT, BSPF), Fusion, Welding
- Working Pressure: 150 PSI
- Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
- Actuator's Lowest Air Pressure: 45PSI; Max.Operating Pressure: 120PSI
- Valve body color : PVC(dark gray), CPVC(light gray),
- PP(light yellow), PVDF(ivory)
Handle Level Butterfly Valve
DESCRIPTION:
- Material: PVC, CPVC, PP, PVDF
- Size: 1/2' - 4'; 20mm - 110mm; DN15 - DN100
- Standard: ANSI, DIN, JIS
- Joint End: Socket, Threaded(NPT, PT, BSPF), Fusion, Welding
- Working Pressure: 150 PSI
- Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
- Actuator's Lowest Air Pressure: 45PSI; Max.Operating Pressure: 120PSI
- Valve body color : PVC(dark gray), CPVC(light gray),
- PP(light yellow), PVDF(ivory)
Worm Geared Butterfly Valve
DESCRIPTION:
1) Material: PVC, CPVC, PP, PVDF
2) Size: 8" - 12"; 225mm - 315mm ; DN200 - DN300
3) Standard: ANSI, DIN, JIS
4) Joint End: Flanges
5) Working Pressure: 150 PSI
6) Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃) 7) Valve body color : PVC(dark gray), CPVC(light gray), PP(light yellow)
Flanged Check Valve
DESCRIPTION:
1) Material: PVC, CPVC, PP
2) Size: 1/2' - 2'; 20mm - 63mm ; DN15 - DN50
3) Standard: ANSI, DIN, JIS
4) Joint End: Flanges
5) Working Pressure: 150 PSI
6) Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
7) Valve body color : PVC(dark gray), CPVC(light gray), PP(light yellow)
Ball Check Valve
DESCRIPTION:
1) Material: PVC, CPVC, PP
2) Size: 1/2' - 2'; 20mm - 63mm ; DN15 - DN50
3) Standard: ANSI, DIN, JIS, CNS
4) Joint End: Socket or Threaded(NPT,PT,BSPF), Fusion, Welding
5) Working Pressure: 150 PSI
6) Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
7) Valve body color : PVC(dark gray/white), CPVC(light gray), PP(light yellow)
Pneumatic Actuated Butterfly Valve
DESCRIPTION:
1) Material: PVC, CPVC, PP, PVDF
2) Size: 1½" - 12"; 50mm - 315mm ; DN40 - DN200
- Standard: ANSI, DIN, JIS
- Joint End: Flanges
- Valve's Working Pressure: 150 PSI
- Actuator Lowest Air Pressure: 45PSI; Max.Operating Pressure: 120PSI
- Operating Temperature: PVC(0~55℃); CPVC & PP(0~95℃)
- Valve body color : PVC(dark gray), CPVC(light gray), PP(light yellow)
