Charpy impact tester is manufactured as per ASTM D 6110 and ISO standard. These models are used by injection moulds & engineering plastic manufacturers. Also charpy impact tester has wide importance in testing polypropylene pipe manufacturing industry for testing the PPR pipe.

Notch cutter is a requirement for making notch on charpy impact samples. Thus notch cutter is also supplied along with this equipment. Charpy impact tester and Izod impact tester are those material testing equipment that are used to check the axial impact on molecular structure of material and thus measure the failure of polymers under impact. condition.

Specification:

Capacity : Up to 25.00 Joules.
Release angle of pendulum: 150 degree.
Range of four scales : 0-2.71 Joules, 0-5.42 Joules,
0-10.84 Joules, 0-21.68 Joules and 0-25.00 Joules.
Minimum resolution on scale: 0.02 Joule, 0.05 Joule,
0.1 Joule, 0.2 Joule and 0.2 Joule respectively.
Paint : Powder coated.
Power : 230 Volts, 50Hz, single phase.

Direct display through microcontroller:
Impact strength in joules/meter and kg-cm/cm.

Graphic display and printout through PC: Impact energy Vs Angular displacement graph and numeric reports consisting of values for impact strength as per ASTM standard, ISO and IS standard in different units could be obtained by attaching a printer to the PC.
